84 HH Quilt Magenta Burst
Gloss finished alder body with AAAA quilt maple veneer top, satin-finished hard maple neck with Kramer SlimTaper™ C profile, compound radius ebony fretboard, matching color non-angled banana headstock with quilt maple veneer, direct-to-body mounted Kramer USA Eruption T humbucker™ pickups, coil splitting toggle switches, Floyd Rose® 1000 series tremolo and rear-mounted R2 locking nut, premium gig bag

A modern take on the legendary Kramer 84, with expanded features, an ebony fretboard, AAAA quilt maple top veneer, and all of the hard rockin’ attitude intact
The Kramer 84 HH Quilt is an updated version of the legendary Kramer 84. While it has expanded features, we’ve kept all of the Made to Rock Hard Kramer attitude of the originals. The Kramer 84 HH Quilt is outfitted with an alder body with a gorgeous AAAA quilt maple veneer top. The body is equipped with a Floyd Rose® 1000 Series tremolo paired with an R2 locking nut for vibrato bar gymnastics without the worry of knocking things out of tune. The neck is a thermally aged bolt-on hard maple neck with a satin finish and an ebony fretboard that has 22 jumbo frets and pearloid dot inlays. The neck has a Kramer SlimTaper™ C profile that is thin and fast, so it is ideal for shredding. The fretboard features a compound radius that is 10” at the nut and flattens out to 14” further up, so playing first-position chords is easy while allowing you to play deep string bends further up the neck without the notes fretting out. The dual-action truss rod is adjusted with a spoke wheel-style truss rod adjustment nut, which is positioned at the end of the fretboard for unfettered access. The body’s gloss finish is duplicated on the front of the 84 non-angled big banana headstock, and the front of the headstock has a matching quilt maple veneer. The 84 HH Quilt’s headstock has a classic Kramer logo, is fitted with die-cast tuning machines, a nickel string retaining bar, and has a wrench holder for the Floyd Rose on the rear, so you’ll always have the tools to adjust the tremolo on hand.
The updated electronics feature a pair of Kramer USA-made Eruption pickups that were designed by Gibson Master Luthier Jim DeCola. Instead of having mounting rings, the pickups are screwed directly into the body for enhanced sustain. A 3-way toggle pickup selector switch allows you to use each pickup by itself or together, and two mini toggle switches (one for each pickup) are provided for coil splitting, giving you a choice of humbucker™ and single coil tones that you can combine at will. A single master volume control with a retro-style black fluted knob controls the overall volume level of both pickups simultaneously, making it easy to crank things up for your awe-inspiring solos. A Kramer premium gig bag is included with the Kramer 84 HH Quilt to keep this Made to Rock Hard shredder safe when you’re traveling to your next gig.
Key Features:
Gloss-finished alder body with AAAA quilt maple veneer top and matching headstock
Satin-finished thermally aged hard maple neck with compound radius ebony fretboard
22 jumbo frets
Two Kramer USA Eruption pickups with individual coil split mini toggle switches
Floyd Rose 1000 Series tremolo and R2 locking nut
Premium gig bag included
Body Style
Double Cut
Body Shape
84 HH
Body Material
Alder
Top
AAAA Quilt Maple Veneer
Body Finish
Gloss Body, Satin Neck
Profile
Kramer SlimTaper C
Scale Length
647.7 mm / 25.5 in
Fingerboard Material
Ebony
Fingerboard Radius
Compound
Neck Material
Thermally Aged Hard Maple with Walnut Skunk Stripe and Truss Rod Adjustment Spoke Wheel
Neck Finish
Natural Satin
Fret Count
22
Frets
Jumbo
Nut Material
Floyd Rose R2 Locking; Rear Mounted
Nut Width
413.0 mm / 16.259 in
Inlays
Pearloid Dot
Joint
Bolt On with Nickel Kramer Back Plate
Finish
Nickel
Bridge
Floyd Rose 1000 Series Tremolo
Tuning Machines
Die Cast
Pickguard
None
Truss Rod
Dual Action
Truss Rod Cover
None
Control Knobs
Retro Fluted
Control Covers
Black
Strap Buttons
2 - Bottom and Upper Horn
Mounting Rings
None
Pickup Covers
None
Neck Pickup
Kramer USA Eruption R
Bridge Pickup
Kramer USA Eruption T
Controls
Master Volume; Two Mini Toggle Switches (One Per Pickup) for Coil Splitting
Pickup Selector
3-way Toggle
Output Jack
1/4" Nickel Barrel Jack; Flush Mounted
Strings Gauge
.010, .013, .017, .026, .036, .046
Case
Premium Gig Bag
Accessories
Wrench Holder on Headstock Rear
Disclaimer: In order to continually improve the design, quality and performance of our products and instruments and to make use of the best materials at all times, Kramer reserves the right to change specifications without notice.
